Ocean Scout performance
The FLIR Quasar™ Quad Sensor Camera is designed to address any application
that requires full coverage of a wide area surveillance, with either a 180° or
360° degree fi eld of view. Thanks to its patent-pending, one-step conversion
process, the camera features a single form factor that is fi eld-confi gurable
to either 180° or 360° mode. The Quad Sensor capability completes FLIR’s
offering of full, wide-area coverage typically required for city surveillance
deployments, critical infrastructure, airports and any other high-profi le
security applications.
180°/360° FIELD OF VIEW
Display a single, 180° panoramic scene or achieve
full 360° coverage using four individual views and
an optional fi fth sensor to eliminate any blind spots
(purchased separately).
BLENDED 2K VIDEO STITCHING
The Quasar Quad Sensor Camera applies automatic
lens distortion correction when stitched together.
EASY INTEGRATION
The camera features H.264 / H.265 compression
and is compliant with ONVIF Profi le S/G.
QUASAR™
4x2KPanoramic
Wall mode Ceiling mode
The FLIR Quasar™ Quad Sensor Camera is designed to address any application
that requires full coverage of a wide area surveillance, with either a 180° or
360° degree fi eld of view. Thanks to its patent-pending, one-step conversion
process, the camera features a single form factor that is fi eld-confi gurable
to either 180° or 360° mode. The Quad Sensor capability completes FLIR’s
offering of full, wide-area coverage typically required for city surveillance
deployments, critical infrastructure, airports and any other high-profi le
security applications.
